FIEGER FLW 32 louvre windows DOUBLE-GLAZED OR TRIPLE-GLAZED OR INSULATED ALUMINIUM PANEL, 28–32 MM

The FLW 32 is our most popular product. A customisable all-rounder with high specifications and cutting edge design. You can choose double-glazed or triple-glazed windows or insulated aluminium panels to suit your requirements.

With high sound absorption properties, when combined with sound insulation glazing to EN ISO 10140-1 / 2, the FLW 32 is also suitable for installation in buildings in high-noise environments.

Our dedicated teams of engineers and designers are always on hand to discuss any elements of your projects and find the best solution to suit your requirements.

Thermally insulated

Uninsulated

You can also find more information about the FIEGER FLW 32 louvre window:

in the data sheet in the data sheet
in the installation drawings/details in the installation drawings/details
in the technical drawings for accessories in the technical drawings for accessories
in the technical drawings for the drives in the technical drawings for the drives
in the CAD data as dwg in the CAD data as dwg
in the CAD data as dfx in the CAD data as dfx
in the Calculator Tool, based on your desired Ug-value and the length-related heat transfer coefficient ψ (Psi). in the Calculator Tool, based on your desired Ug-value and the length-related heat transfer coefficient ψ (Psi).
FLW 32 mit hoher Luftschalldämmung und Schallschutzverglasung nach EN ISO 10140-1 / 2 Aussenansicht École De Drize Carouge, Schweiz

FLW 32

is available with manual, electric and pneumatic drives. The FLW 32 is available with a wide variety of fixing adapters, including 17x32mm and 25x32mm (and 28mm) integral glazing adapters, masonry frame adapters, angle flange frames and bespoke glazing adapters to suit a wide variety of applications.

FIEGER FLW 32 louvre window data at a glance

Feature:

natural smoke and heat exhaust ventilator (NSHEV), smoke extraction from lift shafts


Certification
NSHEV certification in
accordance with
EN 12101-2

Windows and Doors
Product Standard
certified in accordance
with EN 14351-1


Flow coefficient in
accordance with
EN 12101-2
Up to 0,58


Wind load classification
in accordance
with EN 12101-2
WL 3000


Resistance to heat and
mechanical stability
in accordance
with EN 12101-2
B 300-E



Reliability classification
in accordance
with EN 12101-2
Re 1000


Snow load classification
in accordance
with EN 12101-2
SL 0


Low ambient temperature
classification in
accordance with
EN 12101-2
T (-5)


Design:

Louvre blades are flush with frame on the outside. Louvre blades centrally mounted. Glass louvres fully framed. Thermally separated aluminium profiles.

Dimensions
Louvre frames:
Visible frame width 21 mm


Frame depth

42,8 mm

Vent frames:
Visible frame width 40 mm


Frame depth

77mm

Louvre height

200–450 mm
Max frame height
Unlimited (couplable)

Max frame width

2.500 mm



Glazing:

Double-glazed or triple-glazed or insulated aluminium panel with a total thickness of 28 to 32 mm. Dry glazing.

Examination

Watertightness
classification in
accordance with
EN 12208

Class 5a




Air permeability
classification in
accordance with
EN 12207
Class 4




Airborne sound
insulation with sound
insulation glazing
according to
EN ISO 10140-1 / 2

up to
40 dB


Resistance to wind
load EN 12210 / 12211
C3 / B5


Impact resistant
in accordance with
DIN 18032-3

Yes


Fall protection in
accordance with
DIN 18008-4,
Building Regulations,
Section A part 2

Yes





Barrier Load tested
in accordance with
BS6180:2011
Yes



Anti-trap protection
in accordance with
The Machine
Directive 2006/42/EG

SK 3/
SK 4
